You are here: Home > Products > PVD Transceiver > Power Video Data Transceiver(AC/DC)

VT-403(PV)
VT-403(PV)

Video Balun for CCTV with Power

Power,Video over UTP Cable

Transmisja po skrętce

TELEWIZJA PRZEMYSŁOWA

Telewizja dozorowa

Tech Info:

Model NO.

VT-403(PV)

Specs

1ch Passive Power/Video Transceiver

Video

Frequency respons: DC-6Mhz Common-mode/Differential-mode
Rejection: 15khz –6Mhz 60dB type

Audio/data

YES

Power

NO

Impedance

Coax,male BNC:75ΩUTP(Screwless)Terminal Block or
 UTP RJ45 Data Connector:100Ω

Wire type

One Unshielded Twisted Pair 24-16AWG(0.5-1.31mm) Per video signal:DC Loop Resistance 52 ohms per 1,000 ft(18 ohms per 100m)

Surge suppression

6000V 1.2μ S*5μ S

Control

NO

UTP Port

RJ45

Dimensions(mm)

43*20*2.1

Weigth(g)

45

Environment

Temperature:-10~+50℃ Humidity:0~95%
